DC Bluetooth High Bay Sensor
Features & Benefits
The Keilton EFS116 series designed for Luminiare Level Lighting Control (LLLC/NLC5) with integrated photocell and microwave sensors. Photocell threshold setting provides three different values fortreshold On/Off. EFS116 allows machine learning to collect the current light level as treshold value. SC01 and SC02 provide sensor port of EFS116-AUX which is designed for pre-installation of the luminaires. EFS116 has been equiped AlgoH™ algorithm to maximum the detection range without false trigger.
- Plug and Play with Sensor Port Pre-installed
- Bluetooth Network Technology
- Designfor High Bay application
- AlgoH™ algorithm to enhance performance in high bay application
- High Power Microwave module built-in
- Waterprof
- Non-Touch magnet reset
Specifications
Part Number
EFS116-Z10
aaa
aaa
Component Type
Sensor
bbb
bbb
Technology
Bluetooth v5.0
Radio Frequency
2.4G Hz
Transmission Range
80ft
Input Voltage
12V
Aux Voltage
N/A
Control Output
Single 0-10V
Dimmability
0-10V
Color Offering
White
Mouting Height
40ft
Sensor Type
Microwave
Warranty
5 years limited warranty
Certification
FCC, CE compliant, cULus Listed, DLC listed, RoHs, UL1376 Gold
